LOADING BAY SOLUTIONS

Door Seals

High-performance sealing systems that create weathertight barriers between loading docks and vehicles, ensuring thermal insulation, energy savings, and protection from the elements.

Get a Quote

Seal the Gap, Save Energy

Door seals are critical components of any loading bay setup. By creating a tight barrier between the dock opening and the vehicle, they prevent heat loss, block wind and rain, and keep contaminants out of your facility. The right seal type depends on your traffic patterns, temperature requirements, and the range of vehicle sizes you handle.

VARIANT 01

Inflatable Dock Seals

Pneumatically operated sealing systems that inflate around the trailer to form a hermetic barrier. They adapt rapidly to different vehicle sizes, making them the most versatile option for high-traffic loading bays.

  • Rapid inflation and deflation in 10–20 seconds
  • Adapts to varying trailer widths and heights
  • Excellent thermal insulation performance
  • Suitable for temperatures from -30°C to +70°C
Inflatable Dock Seal

VARIANT 02

Mechanical Flexible Seals

Fixed compression seals made from durable rubber, EPDM, or neoprene compounds. They use spring or compression mechanisms to maintain a consistent seal and are ideal for controlled-temperature environments.

  • Extremely durable with minimal maintenance
  • Fire-resistant options available (EI30 rated)
  • Operating range from -40°C to +120°C
  • Ideal for cold storage and food processing
Mechanical Flexible Seal

VARIANT 03

Sponge Seals

Soft polyurethane foam pads that compress against the vehicle body to fill gaps. A cost-effective solution providing moderate thermal insulation and weather protection for standard loading operations.

  • Lightweight and easy to install
  • Good thermal insulation (U < 2.0 W/m²K)
  • Available in 50–150 mm thicknesses
  • Cost-effective for moderate duty cycles
Sponge Dock Seal

VARIANT 04

Retractable Shelters

Mechanically or electrically operated shelters that extend outward to enclose the rear of the trailer. They provide full coverage and superior weather protection while retracting neatly when not in use.

  • Full trailer enclosure for maximum protection
  • Robust steel frame with canvas or PE curtains
  • Load capacity exceeding 500 N/m²
  • Electric or manual operation options
Retractable Dock Shelter

Technical Specifications

Specification Inflatable Mechanical Sponge Retractable
Temperature Range -30°C to +70°C -40°C to +120°C -20°C to +80°C -30°C to +70°C
Primary Material PVC / Polyurethane EPDM / Neoprene PU Foam / Rubber Canvas / PE / Steel
Deployment Time 10–20 seconds Permanent Passive contact 15–30 seconds
Fire Rating On request EI30 (EN 13501-2) Standard On request
Standard EN 12489 EN 12489 EN 12489 EN 12489 / EN 14963

Why Choose Our Door Seals?

Energy Savings

Prevent costly heat loss or cold air escape by maintaining a sealed environment at the dock. Reduce heating and cooling costs significantly across all seasons.

Weather Protection

Keep rain, wind, snow, and dust out of your facility. Protect goods, equipment, and personnel from external weather conditions during loading and unloading.

Versatile Fit

With multiple seal types available, every dock configuration and vehicle fleet can be accommodated — from standard box trucks to oversized refrigerated trailers.

Not Sure Which Seal Is Right for Your Dock?

Our technical team will assess your loading bay requirements and recommend the optimal sealing solution for your operation.

Request a Consultation
